Product Description
The blockhouse facade cladding uses a rigid polyurethane core, which is mounted invisibly (hides the seams) to the supporting structure. Thanks to the special contour of the connecting edge, the necessary screws and special washers are hidden by the protrusion of the next panel. Therefore, the building facade has no visible fastening points. The absolutely unique design of the PERFECT series silhouette is undoubtedly the best.
Product parameters
|
Name of product |
cladding the facade with block house |
|
design style |
Solid color, brick pattern, stone pattern, wood pattern or customized. |
|
Surface material |
Aluminum-zinc alloy steel plate/aluminum |
|
back material |
Aluminum foil fabric |
|
Basic |
Rigid polyurethane foam |
|
paint surface |
High temperature resistant car paint. |
|
color |
customer needs |
|
thickness |
16mm/20mm |
|
length |
Customer choice |
|
weight |
3.5~3.7kg/square meter |
|
Certificate |
ISO9001 |
|
effective width |
383 mm |
|
length |
3800mm, 5800mm (length can be changed) |
|
Fire safety level |
Level B1 |
|
advantage |
Fireproof, waterproof, heat insulation, sound insulation, earthquake resistance, environmental protection, fire resistance and easy installation. |
|
Name of product |
Aluminum foam sandwich panels can be used in hotels, villas, apartments, office buildings, hospitals, schools, shopping malls, prefabricated houses, modular houses and container houses. |
product structure
Manufacturing process
Uncoiler → Embossing (2 sets) → Roll profiling (1 set) → Heating system → PU foam injection → Aluminum foil back film system → Double belt → PLC control system → Flying saw cutting system → Discharging table → Coating machine (4 sets x 12m set)
Product Benefits
|
1 Easy to install: |
Simply screw the product to the steel/wooden frame. |
|
2. Cost reduction: |
Save up to 60% on assembly time and labor costs. |
|
3 Energy saving: |
Thermal conductivity efficiency: 0,019 W/m.k. |
|
4 Thermal insulation: |
Core density: 36.4 kg/m3 |
|
5. Light weight: |
Only 3.17 kg/m2 |
|
6 Environmental protection: |
Construction waste is minimal and 100% recyclable. |
|
7 Ease of maintenance: |
No need to repaint |
|
8 fire resistance: |
Fire resistance level (core): level B1 |
|
Method for determining oxygen index: 26.2% |
|
|
Burning rate index: 211 W/s. |
|
|
9 Waterproof: |
Water absorption (core): 0.9 (v/v)% |
|
Sealing (panel): 1.5 mm |
|
|
bend |
Maximum bending strength: 1.46 kN/m². |
|
force |
Peel resistance: 95% |
|
Cohesive strength: 0,14 MPa. |
|
|
Compressive strength: 0,21 MPa |
|
|
design |
Hundreds of colors and designs, many stunning effects. |
Packaging and delivery
Packaging details
Standard packaging of foam aluminum sandwich panels:
* Packing material: cardboard + protective foam.
* Quantity per package: 910 pcs/box.
* Package size: 3840*420*145 mm.
* Total weight: about 35kg/box.
* 1X20GP container: loading 1500 square meters (panel length: 5.8m).
* 1X40HQ container: loading capacity 3500 square meters (panel length: 3.8m).
port
Dalian Port, Tianjin Port, Qingdao Port
Why choose our foam aluminum sandwich panels?
One of the largest manufacturers of exterior metal siding in China, using advanced Chinese technology.
Many customization options are available (color, design, material, length, packaging, etc.).
We will calculate the approximate material consumption free of charge.
Comprehensive service for the supply of all types of building materials.
Full order tracking.
